BAG VESSEL ASSEMBLY

Filter Concept Pvt. Ltd. is one of the leading Bag vessel assemblies exporters. Bag vessel assembly keeps the filter system on stream by reducing bag filter change time. Bag vessel assemblies are portable and light weight. Bag vessel assemblies advantages are High efficiency filtration, Dynamic large 'O'-ring seal and Knife edge sealing.

Flow Rate

Capacity:Up to 15000 lits /hr Per Unit & More

Operation :

Unfiltered fluid enters the housing and is distributed evenly around the filter bags. Filtration takes place from inside to outside. Solids are collected on the inside of filter bag for easy removal. The filtered fluid then exits through the outlet pipe.

» All polypropylene construction
» High Efficiency filtration
» Micron rating one to 200
» Snap lock bag sealing surface
» Positive sealing of different bag thickness
» Dynamic large "O" Ring Seal
» Compression bag sealing surface
» Knife edge sealing

Material Of Construction [MOC]-Bag Filter Housing

O-ring - Buna-N / EPDM / Silicone

Cap - Polypropylene

Sump - Polypropylene

Gauge - Brass (Optional)

Vent Plug - Polypropylene

Drain Plug - High density Polypropylene (Opt.)

Ball Valve - PVC / Buna-N Seals (Optional)

Basket - Polypropylene / SS 304

Gasket - Buna-N

SIZES

Bag filter system suitable for

» Ø 4” x 10” Long Filter Bag

» Ø 4” x 17” Long Filter Bag

» Ø 6” x 20” Long Filter Bag

Available End connections

» 1” NPT Inline

» 1.5” NPT Inline

» 2” NPT Inline

We have wide expertise and knowledge in the manufacture and export of world-class Bag Vessel Assemblies & Bag Filter Systems. Specialized in application analysis.Our endeavours in this field is backed by a strong R & D support and our own vast experience in dealing with the OEM & End Customer in the various industries like Oil & Gas, Petrochemicals, Power, Steel, Chemicals, Pharmaceuticals, Fertilizers, Dyes & Intermediates, Paint & Ink, Water Treatment etc.

» Filter Housings For Processing Chemicals Industries

» Petroleum Derivatives

» Collants

» Cutting Oils

» Cleaning Fluids

» Vegitable Oils

» Edible Oils

» Polymers

» Paints & Inks Industries

» Resins Applications

» Varnishes

» Lacquers

» Phrmaceutical Industries applications

» Sugar Syrup

» Plastols
