FILTER AND STRAINERS-AUTO BACKWASH STRAINER

Filter Concept Pvt. Ltd. is one of the leading Auto backwash strainer, basket filter strainer, y strainers and t strainers manufacturers. Auto backwash strainers strainers will permit the straining & filtering of a wide variety of fluids, to retain solids of almost any size. All baskets are easily cleanable and removable.

Flow Rate

Capacity: Up to 2000 m3 /hr & More

Basket Filter & Strainers Operation :

Unfiltered liquid enters the basket housing and passes down through them. Solids are retained inside or outside of basket depending upon design and are removed when the unit is serviced. They are available with insitu backwashing arrangement, wherein removal of baskets for cleaning is not required often. Bag filter & strainers are heavy duty baskets. Basket filter & strainers advantages are low pressure drops, Housing are permanently piped, covers are ‘O’ Ring sealed, Carbon steel, or stainless steel (304 Or 316) housing, easy to Clean & Liquid displacers for easier servicing. Basket elements are available in Single, Double & Multi Cylinder Design & Pleated element design.

Duplex Basket Filter & Strainers :

Duplex basket filter & strainer permits continuous operation because flow can be switched back and forth between two filter sections. This allows one side to be serviced while the other is in use. Normally duplex basket filters are separated with three way ball valves or two way ball valve/ butterfly valve connected with equalization tee, between two baskets filter housing.

» Large-area, heavy–duty baskets
» Low pressure drops
» Housing are permanently piped
» Covers are O'-Ring sealed
» Carbon steel, or stainless steel (304 Or 316) housing
» Option of insitu backwashing
» Filtration rating available from 5 micron to 2000 micron & more
» ASME code stamp available
» High pressure rating design available
» Flow rate up to 2000 m3/hr & More
» Customized design available
» High temperature & high pressure design are available
» Pleated element design available for low pressure drop & high dirt hold
» Carbon steel housings are sand blasted, Epoxy coated & finally painted with two coats of synthetic enamel
» Liquid displacers for easier servicing
» Duplex / Triplex & Jacketed units available
» Normally designed for free flow area through screen, 4 – 6 times pipe flow area
» Choice of basket filter elements 1.Single cylinder design | 2. Double cylinder design | 3. Multi cylinder design

Material Of Construction [MOC]-Basket Filter & Strainers

Stainless Steel-316L & SS-316

Stainless Steel-304

SS Duplex [Stainless Steel Duplex]

All Grade Of Carbon Steel [CS]

Mild Steel

Alloy Metals

Polypropylene

Lead Lining with any metals

Rubber Lining with any metals

Teflon Lining with any metals

SIZES

1” Line Size To 24” Line Size & More

Basket element design available

» Single Cylinder Design

» Double Cylinder Design

» Multi Cylinder Design

» Pleated Element Design

Gasket | "O" Ring Material

» Neoprene

» Nitrile

» Silicone

» Viton

» Buna N

» EPDM

» PTFE

Available Valves

» Two way Ball Valve

» Three Way Ball Valve

» Butterfly Valve

We have wide expertise and knowledge in the manufacture and export of world-class Basket Filters & Strainers Specialized in application analysis.Our endeavours in this field is backed by a strong R & D support and our own vast experience in dealing with the OEM & End Customer in the various industries like Oil & Gas, Petrochemicals, Power, Steel, Chemicals, Pharmaceuticals, Fertilizers, Dyes & Intermediates, Paint & Ink, Water Treatment etc.

» Power Plants

» For Process Industries.

» For Refineries.

» For textiles.

» For Chemicals.

» For fertilizers.
